一、概述Introduction

伸縮皮帶機是在普通的帶式輸送機上增加了伸縮機構,使得皮帶機可以在長度方向上自由伸縮。使用者可以按照自己的要求調節,隨時控制輸送機的長度。伸縮皮帶機可雙向運轉輸送物料。伸縮皮帶機可與其它輸送設備和物料分揀系統配合使用,實現物料出入庫或車輛裝卸的自動化生產,在各行業中均得到廣泛的應用。

The telescopic belt conveyor adds a telescopic mechanism to the ordinary belt conveyor, so that the belt conveyor can freely expand and contract in the length direction. The user can adjust according to his own requirements and control the length of the conveyor at any time. The telescopic belt conveyor can transport materials in both directions. The telescopic belt conveyor can be used together with other conveying equipment and material sorting system to realize the automatic production of materials in and out of the warehouse or vehicle loading and unloading, and is widely used in various industries.

二、應用范圍Applied field

伸縮皮帶機在各行業中均得到廣泛的應用?膳c其它輸送設備和物料分揀傳輸系統配合使用,實現物料出入庫或車輛裝卸的自動化生產。

Telescopic belt conveyors are widely used in various industries. It can be used together with other conveying equipment and material sorting transmission system to realize automatic production of material in and out of the warehouse or vehicle loading and unloading.

三、技術參數Technical parameters


型 號 Model

SSC2S-6/4

SSC2S-6/8

SSC2S-6/12

SSC2S-6/14

縮回長度Retracted Length(mm)

6000

延長長度Extended length(mm)

4000

12000

14000

8000

總長度Total length(mm)

10000

14000

18000

20000

高度Height(mm)

750

1200

1000

800

傳送帶寬度Conveyor Width(mm)

1380

1400

1470

1530

皮帶寬度Belt Width(mm)

600/800

皮帶方向Belt direction

可逆Reversible

皮帶速度Belt speed(m/min)

0~36(可調整的adjustable)

輸送能力Capacity(kg/m)

60

傾斜Tilting(°)

0~50° 可通過液壓調節adjustable by hydraulic

驅動電機Driven motor(KW)

1.5KW

2.2KW

3.0KW

4.0KW

重量Weight(t)

2t

3t

4t

5t
